CM Lite

Medium Sized Static Generator CM-Lite

The CM Lite is the mid-sized industrial charging high voltage static generator for static electricity applications like static bonding, static cling or static used to glue materials together. The 20kV generator has fully integrated high voltage parts and only needs a 220V AC Voltage powersupply. The housing is compact and industrially robust and weighs 5,2 kilogram. A compact high voltage supply with an adjustable output voltage (both positive and negative) of 0 – 20 kV (with a maximum current of 0,7 mA) clearly shown on the digital display.

CM Lite

State-of-the art electronics are employed with a remote control option. The power supply is available with a positive or negative output voltage. A warning lamp lights up if the system is overloaded or in the event of spark-over.

CM Lite Highlights

  • Up to 20 kV DC
  • Plug and Play
  • 180° turn-able display
  • IO signals

Full control of static electricity in your production process thanks to the IQ Easy Platform

Features

  • Output voltage of 0 – 20 kV
  • Available with a positive or negative output voltage
  • Remote control is possible
  • A warning lamp lights up if the system is overloaded or in the event of spark-over
  • 180 ° reversible control panel equipped with membrane switches

Technical specification

Housing materialSteel, powdercoating
Weight5,2 kg
Connections4
I/OSub-D 25 p
High voltage readingLCD display
Cable2,5 m with plug and
Euro Connecter IEC-320
Ambient temperature0 – 40 °C
Use circumstancesIndustrial
U primary120 or 230 V AC
Frequency50 or 60 Hz
Power consumption48 Watt
U secondary0 – 20 kV DC
I secondary0 – 0,7 mA
PolarityPos. or neg.
OverloadindicationYes
Switch for locking settingsNo
Standardremote control*
